| Terminal Blade Berbibir Terisolasi | ||||||||||
| ITEM NO | Bahan: Tembaga | Terisolasi: PVC. Nilon | ||||||||
| Dimensi (mm) | Ukuran Kabel | maksimal | Ketebalan | Warna | ||||||
| L | B | F | D | H | mm² | AWG | A | mm | ||
| LBV 1.25-3 | 26.8 | 3.0 | 16.8 | 4.3 | 10.0 | 0,5-1,5 | 22-16 | 10 | 0.75 | Merah |
| LBV 1.25-4.6 | 26.8 | 4.6 | 16.8 | 4.3 | 10.0 | 0,5-1,5 | 22-16 | 10 | 0.75 | |
| LBV 2-3 | 26.8 | 3.0 | 16.8 | 4.9 | 10.0 | 1.5-2.5 | 16-14 | 15 | 0.8 | Biru |
| LBV 2-4.6 | 26.8 | 4.6 | 16.8 | 4.9 | 10.0 | 1.5-2.5 | 16-14 | 15 | 0.8 | |
| LBV 5.5-3 | 29.3 | 3.0 | 16.8 | 6.7 | 13.0 | 4-6 | 12-10 | 24 | 1.0 | Kuning |
| LBV 5.5-4.6 | 29.3 | 4.6 | 16.8 | 6.7 | 13.0 | 4-6 | 12-10 | 24 | 1.0 | |
